Stable Performance Pulsed Plate Practical Fiber Laser Cutting Machine
Product Description
The fiber laser cutting machine adopts the international advanced fiber laser to output the laser beam with high energy density and focus on the working surface, so that the area on the workpiece surface irradiated by the ultra-fine focus spot will melt and gasify instantly, and the automatic cutting is realized by moving the spot irradiation position through the NC mechanical system.
| Model | HN-3015 |
| Working area | 3000mm x 1500mm |
| Rated laser power (optional) | 500W~2000W |
| Traditional system | Gantry double drive structure |
| lubrication system | Fully automatic |
| Maximum speed | 100m/min |
| Maximum acceleration | 1.0G |
| positioning accuracy | ±0.01mm/1000mm |
| Repeated positioning accuracy | ±0.03mm/1000mm |
| Support for graphic formats | CAD, DXF(etc) |
| Total power | 20KW |
| Power demand | Three phase 380V / 50Hz / 60Hz |
| Outline size | 4450mm x 2450mm x 1800mm |
Product details
1. Raycus fiber laser Laser is the "power source" of the core of laser equipment. Like automobile engine, it is also an expensive component in fiber laser cutting machine. At present, fiber lasers on the market include German IPG, rofin, British SPI, American coherent, etc. with the development of technology, domestic lasers such as Ruike and Chuangxin are also emerging, which are gradually recognized by the market for their high cost performance.
For a long time, China's lasers basically rely on imports, which is expensive and has a long supply cycle, resulting in the high price of high-power fiber laser cutting machines. The emergence of a hundred flowers blooming situation for Chinese fiber laser manufacturers has broken the monopoly of foreign enterprises in the laser field and directly lowered the price of imported products.
2. Raytools cutting head The cutting head is the laser output device of the optical fiber laser cutting machine. It is composed of nozzle, focusing lens and focusing tracking system. The cutting head of the laser cutting machine will walk according to the set cutting path, but the height of the laser cutting head needs to be adjusted and controlled under the conditions of different materials, different thicknesses and different cutting methods.
3. Cypcut CNC system The control system is the leading operating system of the fiber laser cutting machine. It mainly controls the machine tool to realize the movement of X, y and Z axes, and also controls the output power of the laser. Its quality determines the stability of the operation performance of the fiber laser cutting machine. Through the accurate control of the software, the accuracy and cutting effect can be effectively improved. At present, Beckhoff CNC system, PA CNC system and farian card system are commonly used.
4. HIWIN / Yaskawa servo motor The motor of laser cutting machine is the core component of the motion system. The performance of the motor directly affects the product processing effect and production efficiency. At present, the commonly used motors include stepping motor and servo motor. Appropriate motors are configured according to the industry type and product type of the processing object.
Stepper motor: fast starting speed, sensitive response, suitable for engraving and cutting with low requirements. The price is low. There are many brands of stepping motors with different performance. Servo motor: fast speed, stable movement, high load and stable performance; The edge of the processed product is smooth and the cutting speed is fast; High price, suitable for industries and products with high processing requirements.
5. Welding machine Fiber laser cutting machine requires very high stability of machine tool. High precision and high stability machine tool is conducive to improve the accuracy of laser cutting. At present, the mainstream machine tools in the market include gantry type, cantilever type and beam type. Different machine tools have different functions. For example, beam type machine tools are mainly used for material cutting of large manufacturers, and there are also models used in specific fields, such as three-dimensional fiber laser cutting, which are mainly used in the automotive industry.
sample
1. Laser cutting machine for automobile manufacturing. Many links in the automobile manufacturing industry can be solved by laser cutting machine. Car doors, body, floor, hood, rear cover, airbag, etc. and some small parts can be processed by laser cutting machine.
2. Hardware laser cutting machine. There are a lot of hardware products, such as bathroom hardware, hotel daily hardware, hardware accessories, hardware crafts, etc., all can be processed by laser cutting machine.
3. Kitchenware laser cutting machine. There are many kinds of kitchenware. Laser cutting machine can meet all kinds of customized production. Whether it is mass production or small batch personalized production, it can be produced as long as there are drawings.
4. Sheet metal laser cutting machine. Many manufacturers only make sheet metal processing, not finished products, then laser cutting machine can be said to be a very good solution, manpower and material costs can be significantly reduced, as long as there is an order, it can start operation immediately.
5. Advertising laser cutting machine. Due to more customization in the advertising industry, the efficiency of using traditional methods is very low. The laser cutting machine will satisfy you no matter how thick the plate is or how many glyphs are.
